Collapsing Dice Tower

This dice tower prints-in-place in the retracted position with no supports but after printing it extends to three times its original height. The drawbridge opens to allow the dice through, but a detent keeps it closed when traveling. The funnel on top and the angle on the bottom mixes the die and makes sure they exit the tower every roll. There is a button on the bottom that locks the tower in position so it wont accidently extended. There is compartment on the bottom for storing dies with a built in catch on the lid.

It is designed to be printed with a .4mm nozzle. The walls are four shells thick, two shells are used for the brick inlay.

If your tower does not extend all the way, pull it apart until you have the desired extension and leave it for a day or two. The plastic will eventually "creep" and you will eventually get the perfect fit.
If when you extend the tower it does not catch soon enough to stay open, increase your “Extrusion Multiplier” or “Flow Rate” depending on the slicer. For example, If the segments are just starting to catch before they are pulled apart, I would increase this facture 10%. In this case, if its set at 1, increase it to 1.1.

Printed on the [Muldex](https://github.com/3dprintingworld/MULDEX) rep-rap IDEX printer
