Drill Guide
Metric Drill Guide
One side of the drill guide is flat for drilling on flat surfaces and one side is v shaped for drilling in corners or on round surfaces such as small pipes or dowels.
The drill guide have eight holes for drill bits from 3mm to 10mm in diameter.
Plenty of room on the sides to write the hole sizes using a felt pen for easy identification.
There is two versions of the drill guide, one that is 20mm tall and one that is 30mm tall.
Supported drill bit sizes: 3mm, 4mm, 5mm, 6mm, 7mm, 8mm, 9mm, 10mm.
