FilaSpoolCase

prusaprinters

::UPDATE:: Added version Z that does not require a spool core (typically comes with Geeetech / Creality printers). ::UPDATE:: Added an adaptor for M6 pushfits - for use with ptfe tube | PC4-M6 for 4mm OD tubing / 1.75mm filament | PC6-M6 for 6mm OD tubing / 3mm filament Note: I find the unthreaded one works better ::UPDATE:: Now snap-able and one size fits all! (fits either 1.75 or 3mm filament) Simplified silica packet compartment and core, and thinned down the base for easier and quicker printing Print instructions The snap-fit pegs are 4mm in diameter Part A comes in 3 different snap-fit hole sizes - the number at the end of the file name corresponds to offset radius: filaspoolcase-X-A-0.05.stl = 0.05mm filaspoolcase-X-A-0.1.stl = 0.1mm filaspoolcase-X-A-0.2.stl = 0.2mm actual hole size = 4mm + 2 x offset radius Use this fit test to determine which one will work best for you: https://www.thingiverse.com/thing:3513594 So if your peg fits, let's say, hole size 4.1 (diameter), then you'd need to print part A size 0.05 (radius) Print without support I used an Anycubic Chiron (400x400x450) Suggestion: tape the seam up with masking tape
