Grey swan
The item consists of a shell and the inner supporting structure.
I did three variants with varying degrees of detail.
"Variant_RODS"-concept only, without optimization supporting structure and stress analysis
A complex support structure requires additional work
(pre-production). Mass 0,423 kg.
"Variant_CLASSICAL" - Simple support structure
Fulfilled strength calculations. Safety factor
1 vertical load, 1,3 diagonal load, 1,5 horizontal load.
Use a standard spherical bearing ADB5 (Astro division).
Mass 0,574 kg
"Variant BONES" - chaotic support structure: pre-concept, render only.
