handyMount
A printable bracket based for handybox to mount on DIN rail. The handymount is based on a template design "dinSpring." This part accomodates two M6 hex nuts in recesses, so you can
1) fasten the handybox to the bracket, then
2) fasten the bracket to the DIN rail
The handybox, with 4 holes, can be fixed in any 90 degree increment for vertical or horizontal fitment.
Fasteners:
► M6x10mm, machine screw
► M6 hex nut
► Spring, from binder clip: Universal PN 10210
Learn more: qr.net/openboxproject
See also: https://grabcad.com/library/dinspring-1
