Keystone Rackmount

Remixed this from the awesome full rack mount version found here https://www.thingiverse.com/thing:3474478

My needs were a bit different. Mine are being used in our Wireless mic cases so they can be easily networked to make changes much much easier, but didn't want to put a full space rail in place. And just printing one was a little to big for it to be stable inside the case.

So i loaded it into tinker cad and sliced it down and moved things around to make it a bit more stable since it would only be mounted on one side of the rack. Instead of punch-down keystone jacks i used coupler versions as our rack tend to change often and since it isn't technically permanent i went for a jumper configuration.

There are 3 flavors to choose from. A super simple 2x a 4x and a double space 8x
instead of printing it at 100% infill i used prusa control to reinforce the rack side all the way up to the wall of the slope with an infill of 70% and the rest is set to 20%

My print times were
2hrs for the 2x
2h 45m for the 4x
5h 30m for the 8x
