Mini box scraper - 160cm wide

need more info? then please leave a comment.
Please honor the time and thoughts put in to these models.
If you need the DXF files for CNC cutting, no problem, send me a PM with e-mail adres.
If you build or change the model please let me know, i'd really like to see what you made from it.

This is a foldable mini boxscraper, used for egalising horse yards and sand pits inside industrial buildings as preparations for the concrete floor.

Using the adjustment in the beam you can set the scraper to follow left or right when scraping next to a wall. Made foldable so it can be easily transported together with the tractor on a small hanger. With the set-up in the picture you can also use a laser\gps on top. Thats where te plates in the corners are used for.

There have been made two models of this box scraper. When you make one extra beam between the wheels to link them together, connect hydraulics of both cilinders together and then directly to the tractor hydraulics. Then you have a easy and cheap to build scraper.

The pitch from the blade in this drawing is 30 degrees for the use of sand. when universally used for dirt and sand its better to make the pitch 60 degrees (steeper). Also in that case u should make increase the radius of the blade so it is more straight up. Otherwise the dirt will not fall off easily.
