mLamp - modular and pivoted LED lamp

prusaprinters

<p>This is an LED table lamp made up of moving parts. The mobility of the parts allows the light to be directed in any direction.</p> <p>This lamp can be modified in various ways.<br/> You can adjust the base (for example, here is a photo of mounting directly on the EIZO monitor).<br/> You can change the final part to use a different light source.<br/> For these purposes, the interconnector model is part of the source files.<br/> You can also change the number and order of individual parts and thus create any arrangement.</p> <p>EDIT: added modification for possibility to use IKEA HEMMA (as option, in user files)</p> <p>video<br/> <figure class="media"> <oembed url="https://youtu.be/qeNZN30m-8c"></oembed> </figure> </p> <p>detailed instruction<br/> <a href="https://drive.google.com/file/d/1kuDGUsXEIren9jZfpOxnPIDr4gDikeE0/view?usp=sharing">https://drive.google.com/file/d/1kuDGUsXEIren9jZfpOxnPIDr4gDikeE0/view?usp=sharing</a></p> <h3>Print instructions</h3><p>The test models were printed from Prusament black PETG with a layer of 0.15 mm.<br/> The attached files are for the default version of the model.<br/> The detailed instructions show how to modify the lamp and create your own modifications.</p> <p>You need the following parts for the basic model:<br/> 6x nut, 6x stopper, 14x join, 6x ring, 4x angle part (left side), 4x angle part (right side), 2x short part (half), 2x long part (half), 1x light base, 2x light cover, 1x light cup, 1x base.</p> <p>For completion you will also need:<br/> LED strip (16x diods), two cords cable, switch, power source for LED strip, Prusament - 1x plastic part of spool, sheet of translucent foil measuring 100 x 50 mm.</p> <p>More information in the detailed instructions in the PDF file.<br/> <a href="https://drive.google.com/file/d/1kuDGUsXEIren9jZfpOxnPIDr4gDikeE0/view?usp=sharing">https://drive.google.com/file/d/1kuDGUsXEIren9jZfpOxnPIDr4gDikeE0/view?usp=sharing</a></p>
