Noodle Machine
Noodle Machine, measured with calipers. I would not stop until it was perfect. I think you can run production with these files.
The Rollers are made of aluminum. They are driven by 3mm thick spur gears, cut by laser router. The spur gears have some notches that make it grip on the rollers. One of the rollers had M7 screw thread to accept the handle.
The bracket to mount the noodle machine to a table is 5mm thick steel. It is bend 90 degrees once. Also laser routed.
The end plates of the noodle machine are 3mm thick laser routed.
The combs on the machine are stainless steel.
The handle is 8mm thick steel rod bend in 2 places, with M7 screw thread on one end.
The rods are 8mm thick steel with M6 screw thread on the ends.
The nuts are M6.
There is a bigger version, but I did not buy the bigger version.
