Rupture Disc
A DN 100 rupture disc is a 100mm diameter pressure relief device. Its specific parts and specifications depend on the model and manufacturer, but common features include a rupture disc (made of materials like stainless steel, nickel, or graphite), a holder, and specific performance characteristics such as burst pressure (from \(0.025\) to \(30\) bar is a common range), burst tolerance (\(\pm 5\%\) to \(\pm 10\%\)), operating temperature limits (\(480\degree C\) for metallic), and material options
