SAMPLE COLLECTOR
MOON SAMPLE COLLECTOR COLLECT SURFACE DUST AND ROCKS AND SORTING IN DIFFERENT SIZE AND PACK IN CYLINDERS.
OTHER WASTE AND DUST IS DUMP BY OTHER SIDE OF SCREW.
SCREW IS ROTATED AT 20 RPM AND PITCH IS 2.5 CM.
DIA OF SCREW PIPE IS 8 CM AND MADE WITH ALUMINIUM.
MOST OF ALL PARTS MADE WITH ALUMINIUM WHICH IS DIRECTLY TOUCH THE SAMPLE.
BODY IS MADE WITH COMPOSITE MATERIAL .
SCREW IS ABLE TO ROTATE FROM ITS MIDDLE POINT BY USING STEPPER MOTOR (MAX 45 DEGREE).
WHEN NO USE OF SAMPLE MECHANISM WE JUST HIDE INSIDE THE ROVER BODY .
NOTE:BODY MATERIAL COLOR IS WHITE BUT FOR INSIDE VIEW WE SELECT TRANSPARENT IN VIDEO.
