squareBox
The most popular square-style handybox, designed based on RACO electrical manufacturer part no. 8192 or 192.
► knockouts for size 1/2 and 3/4 in trade size
► approx 4x4 in profile
► corner tabs with fastener holes designed in
► more accurate than previous square boxes I published
Please Note: knockouts are hole templates cut into the boxes. The holes are not fully cut, but feature sheared metal around 330 degrees of a circle, leaving a round crack and a round metal tab in the wall of the box. This CAD model features some knockouts fully removed, and some represented as "divots." For your design you may need to omit holes that are in this model, or change divots to completed holes. Please adjust the model as you see fit!
