Vacuum Adapter
**Parametric Vacuum Adapter**
Adapt a vacuum hose to fit others.
In workshops the popular fittings are 32mm, 45mm, and 58mm nominally.
► this design is parametric: you can change the parameters and the model updates geometry automatically.
► one end is for female fitment, the other end is male
► each end has a conical shape around 1 degree from straight
► the model adjusts each end from nominal, for fitment.
► ie, the male end of a 45mm fitment is smaller than 45mm to fit a female tube of 45mm
► you can enter any value, but please learn to measure your vacuum first.
► air flows from section A to section B
► the number designation is A first, then B
► the "PRINT" coordinate frame sets end "A" on the print bed
