pro relocation 3d models

This is a relocation of the power unit for a ender 3 pro purchased after or around July 2021 i have also added a cable chain mount that suits Johnniewiskey's chains https://www.thingiverse.com/thing:2920060 Uses original screws from power box, NO...

A quick bracket I drew up to relocate the Electronics box using M5 screws.

Relocates tow strap point higher on scooter to keep thrust below diver for more efficient operation and less fatigue. Recommend use with neoprene buoyancy sheath on front of scooter made from the arm section of wet suit, which also doubles as...

The fifth hole is used to make a ground connection which was eliminated when the PSU was relocated. For the ground, I used a wire connected to the AC ground wire in the wiring box and attached a screw lug to the free end. I then used a T nut and an...

I remixed this excellent idea to accommodate 2 changes: 1: Flipped the PSU so vent slots and fan are facing downward. This is only feasible for printers that have riser feet that introduces space underneath the frame (see thumbnails). Without...

I didn't like how the PSU looked in the stock configuration. I designed this using AutoCAD. The bottom of the PSU is approx 1/4" off the surface when the stock rubber feet are used. I recommend using a different type of feet to raise the whole...

I didn't like how the PSU looked in the stock configuration. I designed this using AutoCAD. The bottom of the PSU is approx 1/4" off the surface when the stock rubber feet are used. I recommend using a different type of feet to raise the whole...

Theses support brackets for the psu relocation were made to fit the original profil and dimension of the Ender 3 pro. I have also included bracket for the rear and front profile to raise the printer by 7 or 12 mm to increase the clearance for the...

You can use it on stock location but I've created it for my printer to relocate extruder from rear wall to side. This allows better printer placement on the bench (NB! Please mind cooling fan grill) Bracket uses thin M4 nuts pressed onto hex...

This adapter allows you to mount an MKS Slot2 SD card Extender into the shell of the QQ-S / QQ-S PRO. - Cut a 3mm x 40mm slot in the shell (I used a dremel with a cutting wheel, and a shop vac while cutting to extract all the metal dust) - Bolt...

This model is a remix of design made by mojobox: https://www.thingiverse.com/thing:4101358 This remix introduces following changes to the design: - fan is facing downward, - increased tolerances, - thinner end plates for less filament consumption, -...

This remix introduces following changes to the design: - fan is facing downward, - increased tolerances, - thinner end plates for less filament consumption, - avoided collision of cable shroud with vertical aluminum extrusion, - unfortunately...

I hate original PSU location it makes bed leveling annoying. I didnt want to post this originally but there you go, it is far from perfect, you need to cut a lot of original metal case and throw away original 30mm fan and use 50x10 instead. you have...

This is a simple case to relocate and replace the original LCD mount. V2 is a little too tall to go under the bed on my machine, but V3 is shorter, but slightly harder to print depending on your machine. For Assembly, I mounted my LCD first, then...

This is a simple case to relocate and replace the original LCD mount. V2 is a little too tall to go under the bed on my machine, but V3 is shorter, but slightly harder to print depending on your machine.</p> <p>For Assembly, I mounted my LCD first,...

Wanted to use bigger spools of filament and placement on top of the QQ-S Pro was not a good idea. So I designed this simple extruder locator which also made able to cut the Bowden tube about 20 cm shorter. You need 3 pcs 12-15 mm long M4 (or M3)...

It Worked well lol

Extruder motor mount to move away from Z-Axis Screw. Comes with the option of two top sections, one with filament runout sensor (using Z-Axis Switch) and the other without. I didnt like how close the filament ran to the Z-Axis screw shaft and was...

Note: You have to press it with some force down on the rail in order to fit. I had to use a wrench. Screen ribbon cable was too short for me. Had to remove cablestrains in order to fit. ...Orderer a new cable on AliExpress.

An Internal LCD Panel for the Ender 3. A Smaller footprint, and also more safety to the LCD board. Warning: It doesnt fit if you're using the stock Printer foots. Print with the LCD side on the bed. Tested with an SKR TFT35 and with the...

<p>Note: You have to press it with some force down on the rail in order to fit. I had to use a wrench.</p> <p>Screen ribbon cable was too short for me. Had to remove cablestrains in order to fit. ...Orderer a new cable on AliExpress.</p> Category: 3D...

The outlet and power switch on the Ender 3 Pro comes out the side and can make it difficult to fit the printer in tight spaces. ... This moves the switch and outlet to the of the psu.

... and involved. Designed these to drill and thru bolt into the power supply housing and rest on the 20/20. Orientation with the holes down to eliminate the need for supports. Creality Ender 5 Pro .15 resolution 25% infill Brim No rafts No supports

Relocated the Y End Stop to the back left for better cable management. I use Klipper so made the stepper_y - position_endstop to 316 (since I lost some dimensions with the AfterBurner mod). ... Use 2 m3 x 6mm bolts to install the end stop and 2 m4...

I liked the case because it relocates the power-cable to the back of the machine. ... Remixed - Replaced the diagonal slits for a honeycomb pattern - Shortened the height to not intervene with the bottom - made the whole to connect to the...

... level surface large enough for the front edge of the LCD acrylic surround to rest on. These mounts WILL SNAP if the front of that piece is not supported. Print Settings Printer: Geeetech i3 Pro B Rafts: No Supports: No Resolution: 0.2mm Infill: 10%

Added a second Z Stepper motor to my Ender 3 Pro. Brackets to mount power supply with kit did not fit. Shelf mounts to side and back of leg and is very stable. Power supply drops into shelf and you don't need screws to hold it if you don't want to. ...

I had a difficult time printing PLA filaments with my CR-5 Pro H so I decided to modify the location of the fan for better cooling of the hotend. This uses the same hotend cooling fan, just repositioned on the top. I removed the top metal cover to be...

This is a power supply relocation for the Tevo Tarantula Pro. This solves the overheating problem of the PSU due to a lack of cooling inside of the original box. Try this if you're having printing stops. This is meant for an 80mm fan. ...The pins hold...

The goal of this bracket is to move the power supply on the Ender 3 or Ender 3 Pro off of the Z axis frame and down onto the base of the printer. This is to reduce the weight on the Z frame in hopes of getting better acceleration performance and less...
